K-Series Hydroheater® Standard Skid

PRODUCT DESCRIPTION

The Industrial Jetcooker™ is perfect for precisely heating liquids and slurries across varying viscosities and solids. Its unique combining tube adjustor allows easy control of process shear, making it ideal for optimal starch conversion.

FEATURES AND BENEFITS

• Patented internal design allows for precise control of steam and turn-down adjustability
• Self-cleaning design eliminates scale build-up and product fouling
• Steam flow control creates consistent, instantaneous mixing and steam velocity while eliminating hammer and vibration
• Choked flow technology accurately meters steam for precise temperature control
• Available in 5 standard sizes with ratings to 2,500 GPM [568 m³/hr]
• Highly compact to meet space constraints
• Pre-designed and partially stocked for short lead time
• Plug-and-play style and custom designs available

APPLICATIONS

• Starch Cooking
• Biofuels
• Anaerobic Digestion
• Starch Conversion
• General Water Heating

PERFORMANCE

• Pressure & Temperature
  • Max Pressure – 300 PSIG / 20.7 Barg
  • Max Temperature – 450°F / 232°C
• Flow Turndown
  • 3:1 turndown ratio (Water)
  • 2:1 turndown ratio (Viscous Slurries)
• Connection Types
  • ANSI Class 150 & Class 300
  • DIN PN16, PN25, PN40
  • Other custom connections available
• Materials of Construction
  • 316 Stainless Steel
  • Other custom materials available

INDUSTRIES

• Chemical
• Pharmaceuticals (Personal Care & Bio Tech)
• Energy & Utilities (Oil & Gas)
• Starch to Sugar
• Paper & Pulp
• Renewable Fuel (Ethanol)
• Mining (Processing Facilities)
• Metal
• Automotive
