EZ Skid™ System

PRODUCT DESCRIPTION

The EZ Skid™ is an integrated, compact pre-engineered hot water set heating system, utilizing the direct steam injection EZ Heater®. All components needed for liquid heating applications are included – simply connect to plant utilities: steam, water, air and power.

FEATURES AND BENEFITS

• EZ Heater bodies are cast 316 Stainless Steel, with 316L internals
• Water piping is 304 Stainless steel, sch 40
• Steam piping is carbon steel, sch 40
• The frame is welded tubing, 304 stainless-steel
• Steam system components are carbon steel, with stainless steel internals as required for performance
• Some components utilize carbon steel bodies with stainless steel trim (larger check valves, automatic on/off steam valves, pumps, etc)
• All-in-one heating system, known as a hot water set, can be easily implemented into your current processes, including heater, skid system, controls and more
• Proprietary SMART Controller is designed to respond to a wide range of flow conditions with a high degree of accuracy
• Internal Recirculation allows a higher turndown ration of 10:1, integrated directly into the skid system
• External Recirculation option allows skid system to continuously maintain on-demand hot water
• Available in 5 standard sizes with ratings to 1,350 GPM [306 m³/hr]
• Highly compact to meet space constraints
• Pre-designed and partially stocked for short lead time
• Plug-and-play style and custom designs available

APPLICATIONS

• Steam & Water

PERFORMANCE

• Max Pressure – 195 PSIG / 13.4 Barg
• Max Temperature – 400°F / 205°C
• H310 – H320: NPT
• H330 – H360: Flanged, ANSI Class 150#

INDUSTRIES

• Beverage
• Dairy (Separation & Pasteurization)
• Food
• Wastewater
• Chemical
• Pharmaceuticals (Personal Care & Bio Tech)
• Energy & Utilities (Oil & Gas)
• Meat & Rendering
• Distilling & Brewing
• Starch to Sugar
• Paper & Pulp
• Renewable Fuel (Ethanol)
• Mining (Processing Facilities)
• Metal
• Automotive
