KSB Amarex Submersible Motor Pump

PRODUCT DESCRIPTION

The Amarex is a vertical single-stage submersible motor pump designed for exceptional performance in wastewater management and industrial applications. Available in stationary and transportable versions, this versatile pump features either a vortex impeller (F-max) or an open dual-vane impeller (D-max), offering superior handling of challenging fluids and debris.

Engineered for reliability and efficiency, the Amarex boasts an impressive overall efficiency of up to 69% and features a patented deflection technology that prevents clogging from wet wipes. The pump's robust construction, including corrosion-resistant stainless steel components and durable bearings rated for 100,000 operating hours, ensures extended service life in demanding environments.

FEATURES AND BENEFITS

• High-efficiency motor meeting IE3 standards for reduced energy consumption
• Patented D-flector and D-max impeller technology preventing clogging
• Free passage up to 100mm with F-max free-flow impeller
• U-shaped ring on claw ensuring perfect sealing between pump and duckfoot
• Eco-friendly, non-toxic oil fill for mechanical seal lubrication
• Wide material variety including cast chrome steel options
• Easy replacement capability with adapter claws
• Available in explosion-proof version (ATEX-compliant)

APPLICATIONS

• Waste water transport and management
• Municipal drainage systems
• Industrial dewatering operations
• Sludge transport
• Water treatment plants
• Commercial and industrial waste handling

PERFORMANCE

• Flow rates up to 330 m³/h (89 l/s)
• Maximum head up to 42 m
• Operating temperature up to 40°C
• Maximum working pressure of 4 bar
• Available in sizes DN 50 to DN 150
