Blue-White FlexPro® Metering Pump

PRODUCT DESCRIPTION

The FLEXFLO® M1 Peristaltic Metering Pump provides reliable, smooth chemical feed for low to medium flow municipal water treatment applications. Its self-priming design does not require check valves or seals that can corrode, clog, or leak. The compact size fits easily into tight spaces, while the simple controls and precision adjustment functions make the operation intuitive.

The FLEXFLO M1 metering pump comes with safety features, including built-in leak detection to prevent false triggering and a lockout mechanism to prevent tampering. Communication and interface ports are easily accessed and protected from dust, moisture, and temperature changes. The convenient “no tools required” cartridge loading design enables quick and easy maintenance.

FEATURES AND BENEFITS

• Self-priming even against maximum pressure.
• Powerful suction - over 30 feet of suction lift.
• Gentle pumping action suitable for shear-sensitive chemicals.
• CNC machined rollers provide optimum squeeze, maximum accuracy, and extended tube life.
• Three chemical-resistant tubing and fitting materials for optimal chemical compatibility.
• Exclusive enhanced tube failure detection (TFD+).
• Convenient hinged door for quick tube changes.

APPLICATIONS

• Municipal water and wastewater treatment.
• Food and beverage.
• Cooling tower water treatment.
• General chemical metering.
• Metal and plastics.

PERFORMANCE

• Feed rates from .0001 to 5.60 GPH (.0004 to 21.2 LPH).
• Maximum working pressure (excluding pump tubes) 100 PSI (6.9 bar).
• Maximum fluid temperature 185°F (85°C).
• Maximum fluid viscosity 5000 cP.
•  Maximum speed 65 RPM.
• Power supply 100 to 240VAC-50/60Hz.
