Chemical Metering Skid Systems

Key Features of Skid-Mounted Chemical Metering Pump Skid Systems

A chemical metering skid system designed to fit the specific needs and requirements of your production line can help save your business time and money while improving overall efficiency.

The key design features that make a chemical metering system a favorable solution are the same features that any skidded system has. Necessary components (e.g. pumps, valves, instruments, control panels) are packaged together to allow for easy installation and a compact footprint. Crane Engineering will custom design to fit the application, with flexibility on materials of construction, feed rates, component manufacturers, and controls strategies.

Here are some of the features and efficiencies that chemical metering skids offer:

• Metering Pumps: Accurate, adjustable flow rate pumps (e.g., diaphragm, piston) for precise chemical injection.
• Accessibility & Maintenance: Crane chemical metering systems are designed for easy operator service and access to necessary equipment like valve handles, pump controls, and instrument displays.
• Flow Measurement: Flow meters and control valves for monitoring and adjusting chemical flow.
• Automation & Control Panel: Crane Engineering can provide a fully integrated controls package for complete automation. This includes drawings package, HMI/PLC programming, and complete networking packages. With an in-house UL 508A panel shop and controls engineers on staff, control panels meet all safety requirements.
• Storage Tank & Level Monitoring: Chemical storage with sensors to monitor levels and prevent shortages.
• Piping & Tubing: Chemical-resistant materials for secure fluid transport.
• Monitoring & Alarms: Real-time system monitoring with alerts for anomalies.
• Ease of Installation and System Integration: Compatibility with other control systems for automation and optimization.

From streamlined operational accuracy to improved dosing accuracy, chemical metering pump skids are a valuable asset to any production line. But which applications benefit most from chemical metering pump skid systems?

Chemical Metering Pump Skid System Capabilities

Manufacturers around the world turn to Crane Engineering for our innovative skid system solutions custom designed to match the production requirements of each unique customer application.

We are fluid technology experts and system integrators with proven examples of system innovation. Crane Engineering offers customers exceptional service and product solutions, including:

• Experience and expertise across multiple industries, including systems for wastewater, food and beverage, general industry, and for pulp and paper/tissue industries.
• All products and panels are built to UL/CUL safety and quality standards.
• We have an elite group of mechanical and electrical engineers with demonstrated system innovation.
• We leverage our distributor status to source the best equipment for the application.
• Disciplined processes in design quality, fabrication, testing and documentation.
• Turnkey skid systems designed for easy serviceability.
• We offer factory acceptance testing of systems before they are shipped and customers are invited to participate.
• On-site commissioning support when requested.

Our Wisconsin-based team manages service and repair across North America, and is laser-focused on providing an unmatched customer experience, and responding promptly to questions and requests. Trust our team to do the same for you.
